Copper Nickel Pipe Manufacturer, Supplier and Exporter in India

Mcneil Instrument, a reputable supplier based in Mumbai, offers an extensive range of copper nickel pipes manufactured to the highest standards. These pipes, composed of copper and nickel, come in various grades such as C70600, C71500, and 90/10, catering to diverse application needs. Renowned for their exceptional corrosion resistance and durability, Mcneil Instrument’s copper nickel pipes find extensive usage in marine and seawater applications.

Complying with ASTM B466 standards, Mcneil Instrument provides copper nickel pipes in sizes ranging from ¼ inches to 12 inches, with varying pressure capacities from schedule 10 to schedule 160. These pipes are available in different lengths, extending up to 13 meters, and can be produced through various methods like rolled, cold drawn, hot finished, stress relieved, annealed, hardened, or tempered. Additionally, they offer pipes with DIN 86019 specifications, suitable for a wide array of applications.

Mcneil Instrument’s copper nickel tubes are tailored to meet industry demands, featuring plain-ended or bevel-ended options and outer diameters ranging from 3mm to 114.3mm. These tubes are manufactured seamlessly, using techniques such as hot rolling, cold drawing, welding, or electric resistance welding. Industries ranging from defense and shipbuilding to refineries and power plants benefit from Mcneil Instrument’s high-quality copper nickel tubes, renowned for their superior strength, corrosion resistance, and longevity.

As a trusted distributor in India, Mcneil Instrument also offers EEMUA 234 UNS 7060X Copper Nickel Tubing, DIN 86019 ASTM B111 C70600 thin and heavy wall welded tubing, as well as finned and copper nickel tube heat exchangers, catering to a diverse range of industrial needs.

Copper Nickel Pipe Specifications

Technical Specification

Seamless and Welded copper nickel pipe suppliers
EEMUA 144 – 16 & 20 Bar
US Standard – Schedule 5S, 10S, 40S, 80S
US Navy Class – Class 20, 700, 50
Grade 90/10 and 70/30
Common Standard of Copper Nickel Pipe manufacturers : ASTM B111/ GB/T8890/ JIS H3300/ BS EN12451 and so on.
Material: BFe10-1-1 / CuNi9010 / C7060X / C70600 /CuNi10Fe1Mn / Cu90Ni10 and BFe30-1-1 / C71500 / CuNi7030 / CuNi30Mn1Fe / Cu70Ni30 or other cuni alloy

Manufacturer & supplier of	Copper Nickel Pipes/ Tubes and Heat Exchanger Tubing
Grades	Copper Nickel 90/10 (C70600 ), UNS C71640, Cupro Nickel 70/30 (C71500)
Copper Nickel Pipe/ Tube	ASTM B466 C70600, CuNi 90/10, ASME B36.19 M, DIN 86019, EEMUA 144 and MIL-T-16420, Material:CuNi10Fe1.6Mn
Specifications	ASTM / ASME SB 111 /SB 151/ SB 466 / 7060X/ CuNi10Fe1.6Mn/ CN102
European Standard	10 bar & 14 bar DIN 86019 / BS 2871 CN102 90/10 CuNi
Standard	ASTM B466, ASME B36.19, DIN 86019, EEMUA 144, EEMUA 234, MIL-T-16420K,
Size	1/2″ – 20″ IN, DN15 TO DN500, 1/2″ TO 6′ IN OD & NB IN Various SWG & SCH
OD	15mm to 508mm
Wall Thickness	Between 1mm and 11 mm
Length	6 meter / custom / Single Random, Double Random & Required Length
End	Plain End, Beveled End, Treaded
Manufacturing process	Seamless / Welded / EFW / ERW / Fabricated / CDW
Pipe Pressure Rating	10bar, 14bar for DIN 86019 16bar, 20bar for EEMUA 144 EEMUA 234 Class 200, Class 700 for MIL-T-16420K
Manufacturer of	Copper Nickel Seamless Pipe/ Tube less than 419mm ( included 419mm) Copper Nickel Seam Welded Pipe/ Tube ( over 419mm )
Pipe Schedule	SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Cuni Pipe and Tube forms and shapes	Round Pipes/ Tubes, Rectangular Pipe/ Tubes, Square Pipes/ Tubes, Coiled Tubing, Pan Cake Coils, U Bend Tubes, “U” Shape, Mechanical & Hydraulic Tubes
Copper Nickel Tube/ Pipe Grades	Copper Nickel 90/10 (C70600) Cupro Nickel 70/30 (C71500) UNS C71640 ASTM B111 for UNS C70600 tubes ASTM B466 for UNS C70600 pipes
Standard tempers	Soft annealed (O60), Hard drawn (H80), Light drawn (H55), and hard drawn & end annealed (HE80)
Other Nickel Alloy Pipe in stock	Inconel 600 Pipe Inconel 600 Tubing Inconel 625 Pipe Inconel 625 Tube Inconel 718 Tube Incoloy 800 Pipe Incoloy 800 Tube Incoloy 800H Pipe Incoloy 800HT Tube Incoloy 825 Pipe Incoloy 825 Tube Hastelloy Tubing Hastelloy C22 Tube Hastelloy C276 Pipe Hastelloy C276 Tube Monel Tubing Monel 400 Pipe Monel 400 Tube Monel K500 Tube Alloy 20 Pipe Alloy 20 Tube

American standard and specification of Copper Nickel Pipe manufacturers

ASTM B469	Seamless Copper Alloy Tubes for Pressure Applications
ASTM B466	Seamless Copper Nickel Pipe suppliers
ASTM B552	Seamless & Welded Cupro Nickel Tube suppliers for Water Desalting
ASTM B543	Welded Copper & Copper Alloy Heat Exchanger Tube
ASTM B608	Welded Copper Nickel Tube/ Pipe
ASTM B467	Welded Cupro Nickel Pipe manufacturer India
ASTM B111	Copper & Copper Alloy Seamless Condenser Tubes & Ferrule Stock
ASTM B359	Copper & Copper Alloy Seamless Condenser & Heat Exchanger Tubes with Integral Fins

UNS C70600 Pipe Equivalent

Grade	USA	U.K	Germany	Japan
China BG	ASTM	BS	DIN	JIS H
BFe10-1-1	C70600	CN102	CuNi10Fe1Mn	C7060
BFe30-1-1	C71500	CN107	CuNi30Mn1Fe	C7150

Cunifer DIN 17664 Tube Equivalent Grades

ASTM B111	C70600
ASTM B466	C70600
EEMUA 144	7060X
KS D5301 JIS H3300	C7060T
BS2871 {PART2}	CN102
AS1752	C70600
DIN17664	CuNi10Fe 1Mn
DIN 86019 WL2.1972	CuNi10Fe 1.6Mn
EN12449	CW352H
MIL-T-16420K	706

Copper Nickel Tubing Sizes

¼” Standard (SCH 40) thru 10”
¼” Extra Heavy (SCH 80) thru 4”
½” Class 200 Mil-T-16420 K thru 10”

70/30 Copper Nickel Pipe/ Tube

Manufacturer & supplier of	Specification
Tube, Condenser, Copper Nickel 70/30	ASME SB111, ASTM B552, B111, MILITARY MIL-T-15005, SAE J463, J461
Tube, Finned, Copper Nickel 70/30	ASME SB359, ASTM B359, MILITARY MIL-T-22214
Tube, Seamless, Copper Nickel 70/30	ASME SB466, ASTM B466, MILITARY MIL-T-16420
Tube, U-Bend, Copper Nickel 70/30	ASME SB395, ASTM B395
Tube, Welded, Copper Nickel 70/30	ASME SB543, ASTM B543

Copper Nickel 90/10 Pipe and Tube

ASTM Designation UNS C70600: ASTM B111
ASME Designation UNS C70600: ASME SB111

Manufacturer & supplier of	Specification
90/10 Copper Nickel Pipe/ Tube, Seamless	ASTM B466, ASME SB 466
90/10 Cuni Tubing/ Pipe, Welded	ASTM B608, B467, ASME SB 467
90/10 Copper Nickel Tube, Condenser	ASME SB111, ASTM B552, B111, SAE J463, J461, MILITARY MIL-T-15005

ASTM B466 UNS C70600 copper nickel seamless pipe

ASTM B466 UNS C70600 Tubes Size	15 NB to 150 NB IN
Cupro Nickel 90/10 Tubing Wall Thickness	.035″ -.095′, (special wall thicknesses available)
Specialized in	Large Diameter Size
UNS C70600 Tubing Type	Straight Copper Nickel 90/10 tube pancake coil Copper Nickel 90/10 tube capillary Copper Nickel 90/10 tube Seamless / ERW / Welded / Fabricated / Hollow
Temper	HARD TEMPER OR SOFT
Hardness	1/8 hard, 1/6 hard,3/8 hard, 1/2hard, 1/4 hard, full hard, soft, etc
Surface	mill, bright, oiled, polished, hair line,sand blast, brush, mirror, or as custom
Application & Uses	Cuni 90/10 Pancake Coil for ACR, General Engineering purpose LWC Coil for ACR Inner-grooved Cuni 90/10 tube for ACR and Refrigeration Straight Cuni 90/10 Tubes for ACR and Refrigeration PE-coated copper Nickel 90/10 tube for gas, water, and oil transportation system Cupro Nickel 90/10 Pipe for Transportation System of gas, water, and oil Copper Nickel 90/10 tube, Semi-finished for industrial use

Copper Nickel Tube Pressure Rating

			10 bar
Pipe Outside diameter			Wall THK	Weight	Pressure
nominal		actual	actual	(theoretical)	Rating
inch	DN	mm	mm	kg/m

0.125		10	1.0	0.26	10
0.25		12	1.0	0.31	10
0.38	10	16	1.0	0.42	14
0.5	15	20	1.0	0.53	14
0.75	20	25	1.5	0.99	14
1	25	30	1.5	1.20	10
1.25	32	38	1.5	1.54	10
1.5	40	44.5	1.5	1.81	10
2	50	57	1.5	2.34	10
2.5	65	76.1	2.0	4.16	14
3	80	88.9	2.0	4.88	10
4	100	108	2.5	7.41	14
5	125	133	2.5	9.16	10
6	150	159	2.5	10.99	10
7	175	193.7	2.5	13.43	10
8	200	219.1	3.0	18.21	10
10	250	267	3.0	22.24	10
12	300	323.9	4.0	35.94	10
14	350	368	4.0	40.9	10
16	400	4191	4.0	46.62	10
18	450	457.2	4.0	50.91	10
20	500	508	4.5	63.63	10
24	600	610	5.0	84.96	10
28	700	711	6.0	118.80	10
32	800	813	6.0	135.99	10
36	900	914	8.0	203.57	10

DIN 86019 Copper Nickel Pipe Dimensions

Outside diameter of pipe			10 bar		14 bar
			Wall thickness (WT)	Theoretical weight chart	Wall thickness (WT)	Theoretical weight chart
nominal		actual	actual		actual
inch	ND	mm	mm	Kg/m	mm	Kg/m
0.125		10	1	0.26	1	0.26
0.25		12	1	0.31	1	0.31
0.38	10	16	1	0.42	1	0.42
0.5	15	20	1	0.53	1	0.53
0.75	20	25	1.5	0.99	1.5	0.99
1	25	30	1.5	1.2	1.5	1.2
1.25	32	38	1.5	1.54	1.5	1.54
1.5	40	44.5	1.5	1.81	1.5	1.81
2	50	57	1.5	2.34	1.5	2.34
2.5	65	76.1	2	4.16	2	4.16
3	80	88.9	2	4.88	2.5	6.07
4	100	108	2.5	7.41	2.5	7.41
5	125	133	2.5	9.16	3	10.95
6	150	159	2.5	10.99	3	13.14
7	175	193.7	2.5	13.43	3.5	18.7
8	200	219.1	3	18.21	3.5	21.19
10	250	267	3	22.24	4	29.55
12	300	323.9	4	35.94	5	44.78
14	350	368	4	40.89	5.5	56
16	400	419.1	4	46.62	6	69.6
18	450	457.2	4	50.91	6	76.03
20	500	508	4.5	63.63	6.5	91.55
24	600	610	5	84.96	8	135.26
28	700	711	6	118.8	9	177.45
32	800	813	6	135.99	10	225.53
36	900	914	8	203.57	11	278.98

Copper Nickel Pipe Wall Thickness Chart

Mcneil Instrument, a prominent distributor and supplier of copper nickel tubing based in Mumbai, offers a comprehensive wall thickness chart for these pipes.

ASTM B466 UNS C70600 Tubes (O.D.)	Cupro Nickel 90/10 Tube Gauge
	BWG 00	BWG 0	BWG 1	BWG 2	BWG 3	BWG 4	BWG 5	BWG 6	BWG 7	BWG 8	BWG 9	BWG 10	BWG 11	BWG 12	BWG 13	BWG 14	BWG 15	BWG 16	BWG 17	BWG 18	BWG 19	BWG 20	BWG 21	BWG 22	BWG 23	BWG 24
	Copper Nickel 90/10 Tubing Wall Thickness (Inches)
	0.380	0.340	0.300	0.284	0.259	0.238	0.220	0.203	0.180	0.165	0.148	0.134	0.120	0.109	0.095	0.083	0.072	0.065	0.058	0.049	0.042	0.035	0.032	0.028	0.025	0.022
	UNS C70600 Tubes Inside Dia
1/4″	N/A	N/A	N/A	N/A	N/A	N/A	N/A	N/A	N/A	N/A	N/A	N/A	0.010	0.032	0.060	0.084	0.106	0.120	0.134	0.152	0.166	0.180	0.186	0.194	0.200	0.206
3/8″	N/A	N/A	N/A	N/A	N/A	N/A	N/A	N/A	0.015	0.045	0.079	0.107	0.135	0.157	0.185	0.209	0.231	0.245	0.259	0.277	0.291	0.305	0.311	0.319	0.325	0.331
1/2″	N/A	N/A	N/A	N/A	N/A	0.024	0.060	0.094	0.140	0.170	0.204	0.232	0.260	0.282	0.310	0.334	0.356	0.370	0.384	0.402	0.416	0.430	0.436	0.444	0.450	0.456
5/8″	N/A	N/A	0.025	0.057	0.107	0.149	0.185	0.219	0.265	0.295	0.329	0.357	0.385	0.407	0.435	0.459	0.481	0.495	0.509	0.527	0.541	0.555	0.561	0.569	0.575	0.581
3/4″	N/A	0.070	0.150	0.182	0.232	0.274	0.310	0.344	0.390	0.420	0.454	0.482	0.510	0.532	0.560	0.584	0.606	0.620	0.634	0.652	0.666	0.680	0.686	0.694	0.700	0.706
7/8″	0.115	0.195	0.275	0.307	0.357	0.399	0.435	0.469	0.515	0.545	0.579	0.607	0.635	0.657	0.685	0.709	0.731	0.745	0.759	0.777	0.791	0.805	0.811	0.819	0.825	0.831
1″	0.240	0.320	0.400	0.432	0.482	0.524	0.560	0.594	0.640	0.670	0.704	0.732	0.760	0.782	0.810	0.834	0.856	0.870	0.884	0.902	0.916	0.930	0.936	0.944	0.950	0.956
1 1/8″	0.365	0.445	0.525	0.557	0.607	0.649	0.685	0.719	0.765	0.795	0.829	0.857	0.885	0.907	0.935	0.959	0.981	0.995	1.009	1.027	1.041	1.055	1.061	1.069	1.075	1.081
1 1/4″	0.490	0.570	0.650	0.682	0.732	0.774	0.810	0.844	0.890	0.920	0.954	0.982	1.010	1.032	1.060	1.084	1.106	1.120	1.134	1.152	1.166	1.180	1.186	1.194	1.200	1.206
1 1/2″	0.740	0.820	0.900	0.932	0.982	1.024	1.060	1.094	1.140	1.170	1.204	1.232	1.260	1.282	1.310	1.334	1.356	1.370	1.384	1.402	1.416	1.430	1.436	1.444	1.450	1.456
1 3/4″	0.990	1.070	1.150	1.182	1.232	1.274	1.310	1.344	1.390	1.420	1.454	1.482	1.510	1.532	1.560	1.584	1.606	1.620	1.634	1.652	1.666	1.680	1.686	1.694	1.700	1.706
2″	1.240	1.320	1.400	1.432	1.482	1.524	1.560	1.594	1.640	1.670	1.704	1.732	1.760	1.782	1.810	1.834	1.856	1.870	1.884	1.902	1.916	1.930	1.936	1.944	1.950	1.956
2 1/4″	1.490	1.570	1.650	1.682	1.732	1.774	1.810	1.844	1.890	1.920	1.954	1.982	2.010	2.032	2.060	2.084	2.106	2.120	2.134	2.152	2.166	2.180	2.186	2.194	2.200	2.206
2 1/2″	1.740	1.820	1.900	1.932	1.982	2.024	2.060	2.094	2.140	2.170	2.204	2.232	2.260	2.282	2.310	2.334	2.356	2.370	2.384	2.402	2.416	2.430	2.436	2.444	2.450	2.456
2 3/4″	1.990	2.070	2.150	2.182	2.232	2.274	2.310	2.344	2.390	2.420	2.454	2.482	2.510	2.532	2.560	2.584	2.606	2.620	2.634	2.652	2.666	2.680	2.686	2.694	2.700	2.706
3″	2.240	2.320	2.400	2.432	2.482	2.524	2.560	2.594	2.640	2.670	2.704	2.732	2.760	2.782	2.810	2.834	2.856	2.870	2.884	2.902	2.916	2.930	2.936	2.944	2.950	2.956
3 1/4″	2.490	2.570	2.650	2.682	2.732	2.774	2.810	2.844	2.890	2.920	2.954	2.982	3.010	3.032	3.060	3.084	3.106	3.120	3.134	3.152	3.166	3.180	3.186	3.194	3.200	3.206
3 1/2″	2.740	2.820	2.900	2.932	2.982	3.024	3.060	3.094	3.140	3.170	3.204	3.232	3.260	3.282	3.310	3.334	3.356	3.370	3.384	3.402	3.416	3.430	3.436	3.444	3.450	3.456
3 3/4″	2.990	3.070	3.150	3.182	3.232	3.274	3.310	3.344	3.390	3.420	3.454	3.482	3.510	3.532	3.560	3.584	3.606	3.620	3.634	3.652	3.666	3.680	3.686	3.694	3.700	3.706
4″	3.240	3.320	3.400	3.432	3.482	3.524	3.560	3.594	3.640	3.670	3.704	3.732	3.760	3.782	3.810	3.834	3.856	3.870	3.884	3.902	3.916	3.930	3.936	3.944	3.950	3.956
4 1/4″	3.490	3.570	3.650	3.682	3.732	3.774	3.810	3.844	3.890	3.920	3.954	3.982	4.010	4.032	4.060	4.084	4.106	4.120	4.134	4.152	4.166	4.180	4.186	4.194	4.200	4.206
4 1/2″	3.740	3.820	3.900	3.932	3.982	4.024	4.060	4.094	4.140	4.170	4.204	4.232	4.260	4.282	4.310	4.334	4.356	4.370	4.384	4.402	4.416	4.430	4.436	4.444	4.450	4.456
4 3/4″	3.990	4.070	4.150	4.182	4.232	4.274	4.310	4.344	4.390	4.420	4.454	4.482	4.510	4.532	4.560	4.584	4.606	4.620	4.634	4.652	4.666	4.680	4.686	4.694	4.700	4.706
5″	4.240	4.320	4.400	4.432	4.482	4.524	4.560	4.594	4.640	4.670	4.704	4.732	4.760	4.782	4.810	4.834	4.856	4.870	4.884	4.902	4.916	4.930	4.936	4.944	4.950	4.956
5 1/4″	4.490	4.570	4.650	4.682	4.732	4.774	4.810	4.844	4.890	4.920	4.954	4.982	5.010	5.032	5.060	5.084	5.106	5.120	5.134	5.152	5.166	5.180	5.186	5.194	5.200	5.206

Copper Nickel Pipe Price List

CUPRO NICKEL 90/10 PIPE SMLS SIZE : 1 X3.5 MM THK. 77 MTR 2.90	INR 3,870/ MTR
CUPRO NICKEL TUBES 90/10 UNS C70600 SEAMLESS PIPE ASTM B466 88.9 MM O.D. X 5.56 MM W.T. X 5580.00 MM L	INR 460/ Kg

Looking copper nickel pipe suppliers in UAE, Singapore, or Australia? Purchase directly from cupro nickel tube manufacturers for optimal pricing and superior material quality. At Mcneil Instrument, you’ll discover a comprehensive range of tubing materials, including Seamless, Welded, Condenser, Heat Exchanger, Heater Tubes, and more, available in all standard sizes and wall thicknesses. Contact Mcneil Instrument for a complimentary quote. Be sure to compare our prices with other Copper Nickel Tube suppliers.

ASME SB111 C70600 Copper Nickel 90/10 Chemical Composition

Elements	Content (%)
Nickel, Ni	9.0-11.0
Iron, Fe	1.0-1.8
Zinc, Zn	1.0
Manganese, Mn	1.0
Lead, Pb	0.05
Copper, Cu	Remainder

Copper Nickel Pipe Weight Per Foot

Outside diameter of pipe			EEMUA 144
Outside diameter of pipe			16 bar		20 bar
ØD			Wall	Theoretical	Wall	Theoretical
ØD			thickness	weight	thickness	weight
nominal		actual	actual		actual
inch	ND	mm	mm	Kg/m	mm	Kg/m
0.125		10	1	0.26	1	0.26
0.25		12	1	0.31	1	0.31
0.38	10	16	2	0.79	2	0.79
0.5	15	20	2	1.01	2	1.01
0.75	20	25	2	1.3	2	1.3
1	25	30	2.5	1.93	2.5	1.93
1.25	32	38	2.5	2.5	2.5	2.5
1.5	40	44.5	2.5	2.95	2.5	2.95
2	50	57	2.5	3.83	2.5	3.83
2.5	65	76.1	2.5	5.17	2.5	5.17
3	80	88.9	2.5	6.07	2.5	6.07
4	100	108	3	8.85	3	8.85
5	125	133	3	10.95	3	10.95
6	150	159	3	13.14	3.5	15.29
7	175	193.7	3	16.07	3.5	18.7
8	200	219.1	4	24.17	4.5	27.12
10	250	267	4.5	33.18	5.5	40.39
12	300	323.9	5.5	49.18	7	62.3
14	350	368	6.5	65.99	8	80.89
16	400	419.1	7	81	9	103.64
18	450	457.2	8	100.93	9.5	119.45
20	500	508	8.5	119.24	11	153.54
24	600	610	10.5	176.79	13	217.97
28	700	711	12	235.58	15	293.22
32	800	813	13.5	303.14	17	380.06
36	900	914	15.5	391.14	19	477.6

Copper Nickel Tubing Melting Point

Property	Minimum Value (S.I.)	Maximum Value (S.I.)	Units (S.I.)	Minimum Value (Imp.)	Maximum Value (Imp.)	Units (Imp.)
Melting Point	1384	1508	K	2031.53	2254.73	°F
Atomic Volume (average)	0.0071	0.0073	m3/kmol	433.268	445.473	in3/kmol
Tensile Strength	267	624	MPa	38.7251	90.5036	ksi
Hardness	580	1650	MPa	84.1219	239.312	ksi
Density	8.5	8.95	Mg/m3	530.638	558.731	lb/ft3
Energy Content	140	180	MJ/kg	15167.4	19501	kcal/lb
Maximum Service Temperature	425	480	K	305.33	404.33	°F
Poisson’s Ratio	0.34	0.35		0.34	0.35
Shear Modulus	45	58	GPa	6.5267	8.41219	106 psi
Bulk Modulus	130	170	GPa	18.8549	24.6564	106 psi
Compressive Strength	85	550	MPa	12.3282	79.7708	ksi
Ductility	0.03	0.44		0.03	0.44
Elastic Limit	85	550	MPa	12.3282	79.7708	ksi
Endurance Limit	138	240	MPa	20.0152	34.809	ksi
Fracture Toughness	26	79	MPa.m1/2	23.6612	71.8937	ksi.in1/2
Loss Coefficient	1.5e-005	0.00056		1.5e-005	0.00056
Modulus of Rupture	85	550	MPa	12.3282	79.7708	ksi
Young’s Modulus	120	156	GPa	17.4045	22.6259	106 psi
Glass Temperature			K			°F
Latent Heat of Fusion	220	240	kJ/kg	94.5825	103.181	BTU/lb

SB 111 C71500 Composition

DIN 86019 2.1972 ( CuNi10Fe1.6Mn)

Cu%	Ni%		Fe%	Mn%	C%	Pb%	S%	P%	Zn%	other
Rem.	9.0-11.0		1.5-1.8	0.5-1.0	Max. 0.05	Max. 0.01	Max. 0.005	Max. 0.02	Max 0.05	_

EEMUA 144 UNS 7060X

Cu%	Ni%	Fe%	Mn%	C%	Pb%	S%	P%	Zn%	other
Balance	10.0-11.0	1.5 – 2.0	0.5 – 1.0	Max 0.05	Max 0.01	Max 0.02	Max 0.02	Max 0.20	0.30

ASTM B466 C70600

Cu%	Ni%	Fe%	Mn%	C%	Pb%	S%	P%	Zn%	other
Balance	9.0 – 11.0	1.0 – 1.8	Max 1.0	Max 0.05	Max 0.02	Max 0.02	Max 0.02	Max 0.50	_

Copper Nickel Heat Exchanger Tubes

Mcneil Instrument excels in possessing exceptional thermal conductivity, seamless joining and sealing capabilities, corrosion resistance, robust mechanical strength, and resilience under harsh and challenging conditions, including fluctuating weather, exposure to salt, and more.

Copper Nickel Condenser Tubes

Copper Nickel Alloy Condenser Tubing sizes

Grade	OD in mm	Wall Thickness (mm)
C68700	3 – 70	0.2 – 5
CuZn20Al2As	3 – 70	0.2 – 5
C44300	3 – 70	0.2 – 5
CuZn28Sn1As	3 – 70	0.2 – 5
C21000	3 – 70	0.2 – 5
C23000	3 – 70	0.2 – 5
C26000	3 – 70	0.2 – 5
C27400	3 – 70	0.2 – 5
C28000	3 – 70	0.2 – 5
C33000	3 – 70	0.2 – 5
C36000	3 – 70	0.2 – 5
C37700	3 – 70	0.2 – 5
C38000	3 – 70	0.2 – 5
C44300	3 – 70	0.2 – 5
C46400	3 – 70	0.2 – 5
C48500	3 – 70	0.2 – 5
C77000	3 – 70	0.2 – 5

EEMUA Copper Nickel Hydraulic Tube Burst Pressure

(Barlow’s Formula)

P = (2ST÷D) (45,000 PSI Min Tensile Stress)
P = Burst Pressure
S = 45,000 lbs. PSI Tensile Strength
T = Nominal Wall Thickness
D = OD/ Outside Diameter

1/4″ x 0.035 – 12,600	5/8″ x 0.083 – 11,950	1-1/8″ x 0.065 – 5,200
1/4 x 0.049 – 17,640	3/4 x 0.035 – 4,200	1-1/8″ x 0.083 – 6,640
5/16″ x 0.035 – 10,080	3/4″ x 0.049 – 5,880	1-1/8 x 0.95 – 7,600
5/16 x 0.049 – 14,110	3/4 x 0.065 – 7,800	1-1/8 x 0.109 – 8,720
3/8″ x 0.035 – 8,400	3/4″ x 0.083 – 9,960	1-1/4″ x 0.065 – 4,680
3/8 x 0.049 – 11,760	3/4 x 0.095 – 11,400	1-1/4 x 0.083 – 5,975
3/8″ x 0.065 – 15,600	3/4″ x 0.109 – 13,080	1-1/4 x 0.095 – 6,840
7/16 x 0.035 – 7,200	7/8 x 0.049 – 5,040	1-1/4″ x 0.109 – 7,848
7/16″ x 0.049 – 10,080	7/8″ x 0.065 – 6,685	1-1/4 x 0.120 – 8,640
7/16 x 0.065 – 13,370	7/8 x 0.083 – 8,535	1-1/2″ x 0.083 – 4,980
1/2″ x 0.035 – 6,300	7/8″ x 0.095 – 9,770	1-1/2 x 0.095 – 5,700
1/2 x 0.049 – 8,820	1″ x 0.049 – 4,410	1-1/2″ x 0.109 – 6,540
1/2″ x 0.065 – 11,700	1″ x 0.065 – 5,850	1-1/2 x 0.120 – 7,200
5/8 x 0.035 – 5,040	1″ x 0.083 – 7,470	2″ x 0.134 – 6,030
5/8″ x 0.049 – 7,055	1″ x 0.095 – 8,550	2″ x 0.188 – 8,460
5/8 x 0.065 – 9,360	1″ x 0.095 – 8,550	2″ x 0.188 – 8,460

Note:
To calculate safe working pressures, the Burst Pressures provided by McNeil Instrument should be divided by the desired safety factor.

Packing: standard export packing
Price Term: CIF CFR FOB Ex-Work
MTC: Yes
Third-party Inspection: Yes
Return/ Cancel policy: Please contact Mcneil Instrument

Supply” conditions=”” of=”” cupro=”” nickel=”” tube=”” manufacturers=”” br=””>

		90/10	90/10 70/30	70/30
IPS	OD	Class 50 Wall	Class 200 Wall	Class 700 Wall	Class 1650 Wall	Class 3300 Wall	Class 6000 Wall
1/4 OD	0.250		0.035			0.035	0.058
1/8	0.405		0.065			0.058	0.095
1/4	0.540		0.065	0.065	0.042	0.072	0.120
3/8	0.675		0.065	0.072	0.049	0.095	0.148
1/2	0.840		0.065	0.072	0.058	0.120	0.203
3/4	1.050		0.065	0.083	0.083	0.148	0.238
1	1.315		0.065	0.095	0.095	0.180	0.300
1-1/4	1.660		0.072	0.095	0.120	0.220	0.380
1-1/2	1.900		0.072	0.109	0.134	0.250	0.425
2	2.375		0.083	0.120	0.165	0.340	0.520
2-1/2	2.875		0.083	0.134	0.203	0.380
3	3.500		0.095	0.165	0.250	0.457
3-1/2	4.000		0.095	0.180	0.284
4	4.500		0.109	0.203	0.340
4-1/2	5.000		0.109
5	5.563		0.125	0.220	0.425
6	6.625		0.134	0.259
7	7.625		0.140	0.284
8	8.625		0.151	0.340
9	9.625		0.187	0.340
10	10.750	0.134	0.187	0.380
12	12.750	0.156	0.250	0.454
14	14.000	0.165	0.250
16	16.000	0.165	0.250
18	18.000	0.180	0.250
20	20.000	0.180	0.250

Mcneil Instrument, an esteemed entity with a rich heritage, stands as a pioneering figure in the industry. Renowned as one of the oldest manufacturers, suppliers, stockholders, wholesalers, traders, dealers, sources, distributors, importers, and exporters, Mcneil Instrument specializes in ASTM B151 Copper Nickel Pipes Tubes. With an unwavering commitment to quality and reliability, Mcneil Instrument serves as a trusted fabricator and stockist, catering to diverse needs with precision and expertise.

1/8″ IPS(.405″ O.D.)	3 1/2″ IPS( 4.000″ O.D.)
SCH 40, 80	SCH 10, 40, 80, 160, XXH
1/4″ IPS(.540″ O.D.)	4″ IPS(4.500″ O.D.)
SCH 10, 40, 80	SCH 10, 40, 80, 160, XXH
3/8″ IPS(.675″ O.D.)	5″ IPS( 5.563″ O.D.)
SCH 10, 40, 80	SCH 10, 40, 80, 160, XXH
1/2″ IPS(.840″ O.D.)	6″ IPS(6.625″ O.D.)
SCH 5, 10, 40, 80, 160, XXH	SCH 5, 10, 40, 80, 120, 160, XXH
3/4″ IPS(1.050″ O.D.)	8 ” IPS(8.625″ O.D.)
SCH 10, 40, 80, 160, XXH	SCH 5, 10, 40, 80, 120, 160, XXH
1″ IPS:(1.315′ O.D.)	10″ IPS(10.750″ O.D.)
SCH 5, 10, 40, 80, 160, XXH	SCH 10, 20, 40, 80 (.500), TRUE 80(.500)
1-1/4″ IPS(1.660″ O.D.)	12″ IPS(12.750″ O.D.)
SCH 10, 40, 80, 160, XXH	SCH 10, 20, 40(.375), TRUE40(.406), SCH80(.500)
1-1/2″ IPS(1.900″ O.D.)	14″ IPS(14.000″ O.D.)
SCH 10, 40, 80, 160, XXH	SCH10 (.188), SCH40 (.375)
2″ IPS(2.375″ O.D.)	16″ IPS(16.000″ O.D.)
SCH 10, 40, 80, 160, XXH	SCH10(.188), SCH40(.375)
2 1/2″ IPS(2.875″ O.D.)	18″ IPS (18.000″ O.D.)
SCH 10, 40, 80, 160, XXH	SCH-40 (.375)
3″ IPS( 3.500″ O.D.)
SCH 5, 10, 40, 80, 160, XXH
